THD 10-1211N, TRACOPOWER THD 10N DC-DC Converter, 5V dc/ 2A Output, 9 → 18 V dc Input, 10W, Through Hole, +85°C Max Temp -40°C

Traco Power DC-DC Converter, DIP-24 Format, 1000μF, Capacitive Load- THD 10N Series - THD 10-1211N

Need a product to provide consistent energy to PCB-linked components? This DC-DC converter from Traco Power is up to the task. It delivers an output of 5V DC so it's suitable for low-power jobs. A versatile input voltage range between 9 and 18V DC makes it a versatile option. The assembly has the oomph to take on challenging conditions as it's housed in a protective metal case that shrugs off bumps and abrasions. Through-hole mounting achieves a permanent and secure hold that prevents shaky connections in high-vibration settings. Thanks to a maximum ripple and noise of just 80mVp-p, interference won't trip up your system's performance.

Features & Benefits

• Performs reliably in a temperature range between -40°C and +85°C
• Light 17.3g weight keeps strain to a minimum
• 85% efficiency means little energy goes to waste
• 1.5kV isolation protects the unit from hazardous overvoltages

Applications

• Industrial power supplies
• Factory automation
• R&D labs

How big is this device?

This DC-DC converter has space-efficient dimensions of 31.8 (L) x 20.3 (W) x 10.2mm (D), so it's a compact option that maximises space on your board.
