1888690, Phoenix Contact MKDSN 2.5/ 3-5.08 Series PCB Terminal Block, 3-Contact

Phoenix Contact COMBICON MKSDN 5.08mm Low Profile PCB Terminal Blocks

5.08mm pitch MKDSN 2,5 series PCB through hole mount terminal blocks with a rising cage clamp screw terminal for a maximum conductor thickness of 2.5mm². These 5.08mm MKDSN 2,5 series PCB terminal blocks have a low profile design and are side interlocking.
Stock numbers 804-5165 and 804-5180 have position markings on the housing
For marker labels see stock numbers 437-3605, 437-3598 and 804-0961
For insertion bridges see stock number 802-0686 (2 way)
For screwdriver see stock number 390-9641

PCB terminal block, nominal current: 24 A, rated voltage (III/2): 400 V, nominal cross section: 2.5 mm², Number of potentials: 3, Number of rows: 1, Number of positions per row: 3, product range: MKDSN 2,5, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: green, Pin layout: Linear pinning, Solder pin [P]: 3.5 mm, type of packaging: packed in cardboard. The article can be aligned to create different nos. of positions!

Approvals

UL (E60425); CSA (LR13631)

Datasheet
