3SU1401-1BB40-1AA0, Siemens SIRIUS ACT Series Light Block, 24V ac/dc, Green Light, Световой блок

Siemens Green LED Light Block, 24V AC/DC Rating, 20mA Current Rating - SIRIUS ACT Series - 3SU1401-1BB40-1AA0

Stay informed about the status of your push button-activated processes with this LED light block from Siemens. You install it behind a button and it illuminates when the button is successfully activated. The light block's green colour follows industry signal codes to indicate that a process is active, quickly informing operators so they can take suitable next steps. With its long-lasting LED bulb, the unit is designed to remain installed for the full service life of its connected push button and eliminate the need to replace components. By consuming just 20mA of current during operation, this device minimises the energy usage of your application.

• Screw-type terminals ensure reliable conductor connections that are easy to install and adjust when needed
• IP40 (ingress protection) rating indicates protection against tools and wires larger than 1mm
• Surge voltage resistance up to 4kV withstands sudden electrical surges without incurring damage

What conductor sizes can I connect to this light block?

The light block supports up to two conductors with cross-sections between 0.5 and 1.5mm². It accepts both solid and stranded cores.

3SU14011BB401AA0 Data Sheet

Siemens SIRIUS ACT - Commanding and Signalling Devices Catalogue (28MB)

Find out more on DESIGNSPARK

Environmental Product Declaration

Environmental Product Declaration - Overview

Siemens EcoTech label
