Intelligent LED Solutions ILS ILK-ANNA-7LED-01 LED Light Kit, Anna Development Kit

ILS Anna Development Kit - 7 LEDs

The Anna Development kits, from Intelligent LED Solutions (ILS), are designed to help the user develop a spotlight design. It includes all the necessary equipment to create and develop a spotlight with a range of characteristics.
The ILK-ANNA-7LED-01 features two PowerAnna 7 LED Coins, in both warm and neutral white colours. The PowerAnna Coins utilise OSRAM’s OSLON SSL 80 LEDs which have a narrow beam angle. A narrow beam angle makes the PowerAnna Coin ideal for use in spotlight applications.
The ILK-ANNA-7LED-01 kit also includes three lenses in a range of beam angle options. The lenses are from the Anna series by LEDiL, which are a large family of versatile optics. The PowerAnna coins are designed to work specifically with the Anna series of lenses.
The Anna Development kit is also available in a 3 LED option 8750025.

ILK-ANNA-7LED-01 kit contents:
1 x PowerAnna 7 LED - 3000K Warm White
1 x PowerAnna 7 LED - 4000K Neutral White
1 x M2.5x4mm Screws
1 x Heat sink 60x50mm - Power board mounted TIM pre fixed
2 x M3x20 Screws with 5 mm spacers
1 x LEDiL Anna Lens 11°
1 x LEDiL Anna Lens 20°
1 x LEDiL Anna Lens 26°
2 x Anna stainless ring holder
1 x M3 45mm Screws
1 x Anna stainless top cap
1 x Constant Current Driver - 350 mA, 8 W
(Please refer to data sheet for part numbers)

Caution

The PowerAnna LEDs, when powered up, are very bright. Thus it is advised that you do not look directly at it. Turn the PowerAnna away from you and do not shine into the eyes of others.
