GST60A24-P1J, MEAN WELL 60W Power Brick AC/DC Adapter 24V dc Output, 2.5A Output, Блок питания

Mean Well Desktop Power Supply

The Mean Well GST60A series desktop power supply is the latest invention with a high-quality adapter and a voltage rating of 24VDC. It provides 60W of continuous output power in a high-quality, compact enclosure suitable for many general power applications. It has an input frequency range from 47Hz to 63Hz. While the input voltage rating ranging from 85VAC to 264VAC/135VDC to 370VDC, its maximum input leakage current is 0.75mA. This product is equipped with a 3-pin standard IEC320-C14 power plug. This power supply boasts an efficiency rating of up to 90.5%, coupled with an extremely low no-load consumption rating of below 0.075W.

Features and Benefits

Output current is 2.5A
Protections for short-circuit, overload and over voltage
Fully enclosed plastic case
Class I power with earth pin
LED indicator for power on
No load power consumption less than 0.075W
ErP level VI compliant
Working temperature ranges between -30°C and 70°C

Applications

Consumer electronic devices
Telecommunication devices
Office facilities
Industrial equipment

Certifications

UL60950-1
TUV EN60950-1
BSMI CNS14336
CCC GB4943
J60950-1EN55022 class B
EN61000-3-2,3
FCC PART 15 / CISPR22 class B
CNS13438 class B
GB9254
GB17625.1
EN61000-4-2,3,4,5,6,8,11
Light industry level, criteria A

Datasheet
