GST90A24-P1M, MEAN WELL 90W Power Brick AC/DC Adapter 24V dc Output, 3.75A Output, Блок питания

Mean Well Desktop Power Supply

The Mean Well GST90A series desktop power supply is the latest invention with a high-quality adapter and a voltage rating of 24VDC. It provides 90W of continuous output power in a high-quality, compact enclosure suitable for many general power applications. It has an input frequency range from 47Hz to 63Hz. While the input voltage rating ranging from 85VAC to 264VAC or 120VDC to 370VDC, its maximum input leakage current is 1mA. This product is equipped with a 3-pin standard IEC320-C14 power plug. This power supply boasts an efficiency rating of up to 90%, coupled with an extremely low no-load consumption rating of below 0.15W.

Features and Benefits

Output current is 3.75A
Protections for short-circuit, overload and over voltage
Fully enclosed plastic case
Class I power with earth pin
LED indicator for power on
No load power consumption less than 0.15W
ErP level VI compliant
Working temperature ranges between -30°C and 70°C

Applications

Consumer electronic devices
Telecommunication devices
Office facilities
Industrial equipment

Certifications

UL60950-1
TUV EN60950-1
BSMI CNS14336
CCC GB4943
J60950-1EN55022 class B
EN61000-3-2,3
FCC PART 15 / CISPR22 class B
CNS13438 class B
GB9254
GB17625.1
EN61000-4-2,3,4,5,6,8,11
Light industry level, criteria A
