1792139, Phoenix Contact 5mm Pitch 14 Way Pluggable Terminal Block, Plug, Cable Mount, Screw Termination

Phoenix Contact 14-pin Pluggable Terminal Block, 5 mm Pitch - MVSTBR 2.5/14-ST - 1792139

Ensure electrical connections to your PCB (printed circuit board) are effective and firm with this pluggable terminal block from Phoenix Contact. You can use it in numerous applications, ranging from control and communication devices to power supplies.
The unit's screw-in wire connectors are maintenance-free thanks to the locking system, which uses spring-loaded elements to hold leads firmly in place. It offers reliable vibration resistance to protect connection points and prevent wires from breaking. Signature green polyamide housing is resistant to abrasion and impact, so it can withstand harsh industrial environments. The connectors accept conductors with diameters ranging from 0.2 mm² to 2.5 mm², making this a versatile choice.
This component has been rigorously tested by the manufacturer for safety and reliability. The durable polyamide material is rated UL94 V-0 by Underwriters Laboratories, meaning it's self-extinguishing within 10 seconds when exposed to flames.

• Current rating of 12 A
• 14 contacts
• Screw connection
• Pitch of 5 mm
• Plug type
• Voltage rating of 630 V
• Weight of 28.6 g

Datasheet

Dimension Sheet - 1792139

Catalogue - Terminal Block
