2700578, Phoenix Contact Optocoupler, Max. Forward 24 V, Max. Input 50 mA DIN Rail Mounting Style, Оптопара

8841165
Номер производителя: 2700578Производитель: Phoenix Contact
Цена за шт.
30114.00 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

PSR Mini PC20 Optocouplers

The PSR Mini PC20 Optocoupler is a coupling relay that can be used for power adaptation and electrical isolation in high and low-demand applications up to SIL 3. When using this module, circuits are interrupted in a safety-oriented manner.
The PC20 safety relay has an interface for the TBUS DIN rail connector via which the diagnostic supply voltage can be routed.

Used in applications up to SIL 3 according to IEC 61508 & EN61511
Used for safety-related switching off
12.5mm housing width
Approved for Class l, Zone 2 applications
Integrated DCS test pulse filter
Low inrush current
2 internal 5AT fuses, TBUS connection
1 undelayed enabling current path
1 undelayed confirmation current path
1 digital signal output
Option of screw or spring-cage terminal blocks for plug-in

Standards

IEC 61508, EN 61511

Техническая спецификация
pdfPSR-PC20 Data Sheet
Вид монтажа:
DIN Rail
Время нарастания:
2мс
Глубина:
114.5мм
Диапазон рабочих температур:
-40 → +70 °C
Максимальное прямое напряжение:
24 В
Максимальный входной ток:
50 мА
Напряжение изоляции:
6кВ
Рабочая температура - максимальная:
+70°C
Рабочая температура - минимальная:
-40°C
Размеры:
12.5 x 116.6 x 114.5 мм
Серия:
PSR-PC20-1NO-1NC-24DC-SP
Специальные функции:
Long Service Life to Filtering of Controller Test Pulses, Approved for Class I, Zone 2 Application
Тип входа:
Постоянный ток
Тип выхода:
Цифровой, PNP
Ширина:
6.8мм
