San Ace Low Power DC Fans - GA Series
San Ace GA series low power DC fans are a highly power efficient solution to a range of fan requirements. Featuring high air flow, high static pressure and low noise.
Low power high performance fans offering 15% to 38% energy saving over conventional fans
Improved impeller, guided vanes, reduced mass, reduced noise by between 2dB and 6dB
PWM control to further optimise power consumption and noise level (except 60 x 60 x10 mm frame size which have tachometer output only)
High static pressure and high airflow
Static pressure optimised at inflection point where fan operated for high impedance applications
30,000 to 60,000 hour life fans @ 60 Degree C
Permanently lubricated dual ball bearing system
Sanyo Denki Axial Fan, 12V DC Voltage Rating, Plastic Material - San Ace 9GA Series - 9GA0612H9001
Need a way to cool down your equipment to prevent it from overheating? Choose this axial fan from Sanyo Denki. Thanks to its high airflow rate of 30m³/h, it provides powerful cooling. The plastic frame and impeller are flame-retardant for safety in the event of a fire. It has a robust lifespan of 40,000 hours at +60°C and 70,000 hours at +40°C, so you can rest assured it will last a long time.
Features & Benefits
• Low power consumption of 1.68W means it's an energy-efficient choice
• Compact dimensions of 60 (H) x 60 (W) x 10mm (D) for installation in confined spaces
• Light weight of 35g to place minimal strain on your equipment
• Broad operating temperature range between -20°C and +70°C for use in challenging conditions
Applications
• HVAC systems
• Electrical cabinets and enclosures
• Production lines
What motor protection system does this axial fan have?
This axial fan has a current blocking function and reverse polarity protection, which help to improve electrical safety and reduce the risk of a breakdown.
Техническая спецификация
