RS PRO Interface Relay, DIN Rail Mount, 24V ac/dc Coil, SPDT, 1-Pole, Реле

RS PRO Non-Latching Relay, SPDT, DIN Rail, 24 V AC/DC, 6 A Switching Current

This non-latching relay from RS PRO is an industrial switch for opening and closing a circuit. When powered up, the relay switches magnetically from 'normally closed' (NC) to 'normally open' (NO), making it ideal for push-button applications such as keyboards and micro-controllers.
This relay has a green LED indicator, making it easy to see whether it's on or off, even in dimly lit workspaces. The broad operating temperature range of -25°C to +60°C means it's able to withstand harsh environments.
In addition to current switching, this product can also be used for measuring, controlling or amplifying signals. It's often found in automotive applications, industrial machinery and telecommunications devices.

Features and Benefits

• Interface application
• Coil voltage of 24 V AC/DC
• Single pole double throw (SPDT) contact configuration
• Silver alloy contact material
• Dimensions of 6.2 (length) x 93 (height) x 73 mm (depth)
• Green LED indicator
• Life of greater than 50000000 mechanical cycles
• Maximum switching voltage of 250 V (AC/DC)
• Operating temperature range of -25°C to +60°C
• DIN rail mounting type
• Single pole
• General-purpose relay switching classification
• Meets Canadian Safety Association (CSA), Germanischer Lloyds (GL) and Underwriters Laboratories (UL) safety standards
• Switching current of 6 A
• Push-in terminal type
