2902035, Phoenix Contact MINI MCR-2-UI-REL-PT Series Signal Conditioner, ATEX, Реле контроля

8903875
Номер производителя: 2902035Производитель: Phoenix Contact
Цена за шт.
65785.20 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

MINI MCR - Limit Value Switches

MINI MCR series limit value switches, with adjustable hysteresis and delay time and spring-cage connection.

Power supply possible via the foot element (T-connector)
Status and error indication via two diagnostic LEDs
PDT relay at output
3-way isolation
Limit value can be freely adjusted via potentioemeter on the front
Highly-compact threshold value switch for switching analog limit values

Phoenix Contact Voltage Monitoring Relay, 24mA, 12V DC - MINI MCR-2-UI-REL-PT - 2902035

This voltage monitoring relay from Phoenix Contact is a remote switching device for opening and closing a circuit. As a limit value switch, it's used to turn moving components on an electrical device on and off.
The relay has three-way isolation, so you can control output signals at two separate points and keep them from interfering with the signal reading for enhanced reliability. The LED (light-emitting diode) lights on the module display its status and indicate errors, so you can quickly react to a fault. You can manually adjust the potentiometer on the front of the relay to change the limit value, making it a versatile choice. Use this relay for automated switching to protect you from electrical currents and switch multiple components at once.

Features & Benefits

• Compact dimensions of 120.5 (length) x 6.2 (width) x 110.5 (height) mean it fits into control systems where space is limited
• DIN rail mounting means it's easy to install
• Wide operating temperature range of -40°C to +70°C for use in harsh conditions
• Screw terminal type for ease of installation without the need for special tools

Техническая спецификация
pdfDatasheet
Встречающиеся стандарты:
ATEX, CCC, CE, cUL, DNV, EAC, EN 60715, EN 60947-5-6, EX-Zone 2, GL, IEC 610101-1, UL
Диапазон рабочих температур:
-40 → +70°C
Рабочая температура - максимальная:
+70°C
Рабочая температура - минимальная:
-40°C
Серия:
MINI MCR-2-UI-REL-PT
Сертификация опасной зоны:
ATEX
Тип монтажа:
Крепление на DIN рейку
