219.1633, Scame IP66 Blue Cable Mount 2P + E Power Connector Plug ATEX, IECEx, Rated At 16A, 200 → 250 V

Scame IP66 Blue Cable Mount 2P+E Power Connector Plug ATEX, IECEx, Rated At 16.0A, 200 → 250 V

Need a plug for use where gas and dust create a risk of explosion? This cable-mount two-pin plus Earth plug from Scame stands up to harsh environments like petrochemical plants, mines and flour mills. The glass fibre-reinforced polyester connector boasts impact resistance higher than 20 J at 20˚C. It's fire-resistant and will not emit halogens or smoke.

The plug is suitable for use with switched interlocked power outlet units and will accept cables between 6 mm and 15 mm. It's voltage rated at 200 → 250 V and amp rated at 16 A.

Exhaustively tested for use in hazardous environments, it's ATEX and IECEx certified in potentially explosive atmospheres and meets European standards on industrial equipment (EN 60079, EN 60309). Its IP66-rated enclosure keeps all dust out and it contains only minimal hazardous substances (RoHS). Plus, it won't damage equipment via electrostatic discharge (ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007).

Features and Benefits

• 2-pin + Earth male power connector plug
• Cable mount
• Highly resistant to impact, aggressive chemical substances and atmospheric agents
• ATEX and IECEx certified for use in potentially explosive atmospheres
• IP66 rated as a dust-tight enclosure
• Voltage rating of 200 → 250 V
• Current rating of 16 A
• Accepts cables between 6 mm and 15 mm
• Working frequency of 50-60 Hz

219.1633 Datasheet
