NGCPA10AX01A1A, Honeywell NGC Series Roller Lever Limit Switch, NO/NC, IP67, SPDT, Plastic Housing, 240V ac Max, 6A Max

Honeywell NGC Series Micro Switch Compact Limit Switches

Honeywell’s MICRO SWITCH™ Compact Limit Switches, NGC Series, are a configurable platform of medium-duty switches that allow the customer to choose SPDT (single pole, double throw) or DPDT (double pole, double throw) circuitry while maintaining the same housing and mounting footprint throughout the NGC Series. The NGC Series can be configured more than 380,000 ways carries global approvals. The compact series limit switches are sealed to IP67 for potential use in indoor and outdoor applications. The Compact switches offer durable packaging allows for use in many harsh indoor or outdoor applications, providing performance confidence .The switches also allow design engineers to standardize on a single footprint while meeting a variety of electrical requirements.
With two times the vibration (10 g) and shock (50 g) ratings of comparable competitive devices, the NGC Series can be implemented in the harshest of environmental conditions, providing enhanced reliability and repeatability
Broader current capacity (10 A) than comparable devices allows for potential use in a wider set of applications, making platform standardization an easier task.

SPDT or DPDT configurable circuitry
Snap-action, positive-break contacts
Silver alloy and gold plated contact options
UL, CE, cUL, and CCC approvals
NEMA 1, 4, 12, 13; IP67 sealing
Metal and plastic housing options
Cable and connector terminations
Variety of heads and actuator levers

POTENTIAL INDUSTRIAL APPLICATIONS
Boom position detection
Elevators and escalators
Machine tools
Mobile light towers
Packaging equipment
Rail doors
Scissor lifts

Honeywell Snap-Action Roller Lever Limit Switch, Positive Break, 240V AC - NGC Series - NGCPA10AX01A1A

Use this limit switch from Honeywell to detect objects in medium-duty applications. It comes encased in durable plastic packaging, making it suitable for use in outdoor applications. The unit has a 10g vibration rating and 50g shock rating, meaning it continues to work reliably even under harsh industrial conditions. A 6A current capacity makes this switch a versatile choice to use across different platforms. Its panel-mount design reduces external strain on the electrical connections, keeping your components in good working condition. It's also a long-lasting product, with a mechanical life of 5,000,000 cycles.

Features & Benefits

• NO/NC (normally open/normally closed) configuration options for versatility in how you set up your circuit
• IP67 (ingress protection) rating means the unit is dust-tight and highly water-resistant
• M12 connection type makes it compatible with industry-standard fixings and components

Applications

• Boom position detection
• Lifts and escalators
• Machine tools
• Mobile light towers

What's a positive break in a limit switch?

Positive break limit switches ensure that all contacts are in the open position when the actuator is in the open position. They do this by mechanically forcing the contacts apart.
