RS PRO Hour Meter Counter, 6 Digit, 10 → 80 V dc, Счетчик часов

RS PRO, 6 Digit, Analogue, Counter, 10 → 80 V DC

This RS PRO six-digit analogue hour counter will reliably tell you exactly how long your equipment has been operating. The total time can be seen in hours and tenths with running indicators.

This unit can be mounted on a DIN (Deutsche Institut für Normung or the German Institute of Standardisation) rail for easy installation. Its overall dimensions are (H) 100 mm, (W) 45 mm and (L) 36 mm, and it's suitable for situations where space is limited. The counter can operate with a range of DC voltage supplies. It can't be reset, has an automatic cycle to zero, and comes with an upwards count direction.

Like any unit in our RS PRO range, its reliability and consistency can be trusted. The counter's enclosure is IP40 rated and so is protected against dust, wires over 1 mm and tools. This type of product is commonly used throughout commerce and industry.

Features and Benefits

• Analogue hour counter
• Spade terminal
• Electronic meter
• Measurement range of 0 to 99999.9 hours
• Minimum operating temperature of -5°C
• Supply voltage of 10 to 80 V DC
• Cut out dimensions of (H) 100 mm x (W) 45 x (L) 36 mm
• Digit height of 3.6 mm
• Six digits
• No reset
• Upwards count direction (incremental)
• DIN rail mounted (Deutsche Institut für Normung or the German Institute of Standardisation)
• Voltage input
• Rectangular
• Analogue display
• Meter accuracy of ±0.02%
• RoHS compliant for minimal hazardous materials
• CE certified for health, safety and environmental protection
• Handled and packed in conditions that meet ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 electrostatic control standards

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
