RS PRO Hour Meter Counter, 6 Digit, 50Hz, 12 → 48 V ac/dc, Счетчик часов

RS PRO Hour Meter Counter, 6-Digit LCD, 50 Hz, 12 to 48 V AC/DC

Need to know how long your machinery has been running? Use this hour meter from RS PRO. You'll find this digital device used in a variety of commercial settings, from industrial garages to electricity exchanges.


The meter is designed for high accuracy, with a display showing up to six digits. It has a remote reset function, meaning you can save time by restarting it at a distance. The LCD (liquid crystal display) consumes low levels of power, so it's an energy-efficient choice.


The device counts in hours with a range from 0 to 99999.99, making it suitable for use with a variety of machinery. This product is Restriction of Hazardous Substances (RoHS) compliant, meaning it contains only minimal amounts of any harmful materials.

Features and Benefits

• CE (Conformité Européenne), RoHS (Restriction of Hazardous Substances), (Underwriters' Laboratory) UL94V0 approvals


• Screw connection type


• Count capacity of 99999.9 h


• Count direction of up


• Count mode of hours


• Cutout height of 24.6 mm


• Cutout size of 37 x 24.6 mm


• Cutout width of 37 mm


• Depth of 36.5 mm


• Digit height of 5 mm


• LCD display type


• Hour meter function


• Voltage input type


• Maximum count frequency of 50 Hz, 60 Hz


• Measurement range of 0 to 99999.9 h


• Meter accuracy of ±0.02%


• Electronic meter type


• Minimum operating temperature of -10°C


• Maximum operating temperature of +50°C


• Flush mounting, panel mounting type


• Six digits


• Remote reset method


• Rectangular shape


• Supply voltage of 12 to 48 V AC/DC


• Weight of 31 g
