RS PRO Hour Meter Counter, 6 Digit, 50Hz, 85 → 265 V ac, Счетчик часов

RS PRO Hour Meter Counter, 6 Digit LCD, 50 Hz, 85 to 265 V AC

Use this hour meter from RS PRO to monitor how long your machinery has been running. To save you time, it has a remote reset function so you can restart it from afar. The LCD (liquid crystal display) is designed for low power consumption, so you don't have to worry about it draining energy from your circuit.


The meter is highly accurate as its display shows up to six digits. It counts from 0 to 99999.99 hours, making it suitable for use with a variety of machinery. You'll find this digital device used in a range of commercial settings, from industrial garages to electricity exchanges.

Features and Benefits

• CE (Conformité Européenne), RoHS (Restriction of Hazardous Substances), (Underwriters' Laboratory) UL94V0 approvals


• Screw connection type


• Count capacity of 99999.9 h


• Count direction of up


• Count mode of hours


• Cutout height of 24.6 mm


• Cutout size of 37 x 24.6 mm


• Cutout width of 37 mm


• Depth of 36.5 mm


• Digit height of 5 mm


• LCD display type


• Hour meter function


• Voltage input type


• Maximum count frequency of 50 Hz, 60 Hz


• Measurement range of 0 to 99999.9 h


• Meter accuracy of ±0.02%


• Electronic meter type


• Minimum operating temperature of -10°C


• Maximum operating temperature of +50°C


• Flush mounting, panel mounting type


• Six digits


• Remote reset method


• Rectangular shape


• Supply voltage of 85 to 265 V AC


• Weight of 31 g
