RS PRO Analogue Panel Ammeter 40A AC, 68mm x 68mm, ±1.5 % Moving Iron, Амперметр

RS PRO Analogue Panel Ammeter 20 A AC, 68 mm x 68 mm, ±1.5% Moving Iron

Need an accurate way to measure and display the current level in an electrical circuit? This RS PRO analogue panel ammeter displays the AC current to a 1.5 currency class, equivalent to a margin of error of 1.5%. You'll find it in industrial settings such as electronics manufacturing facilities, power plants and telecommunications exchanges.
Built to last, the ammeter comes in hardwearing ABS (Acrylonitrile Butadiene Styrene) thermoplastic and polycarbonate housing. The text is easy to read, thanks to the bold black typeface and contrasting white background. You can easily tell when the amperage is too high, as there's a bright red danger zone.

Features and Benefits

• CE (Conformité Européenne), RoHS (Restriction of Hazardous Substances) compliant, TUV (German Equipment and Product Safety Act) certified, UL (Underwriters' Laboratories) E327849 approvals
• AC current type
• Cutout height of 68 mm
• Cutout width of 68 mm
• Depth of 59 mm
• Analogue display type
• Maximum value of 20 A
• Measurement range of 0 to 40 A
• Meter accuracy of ±1.5%
• Minimum displayed value of -25°C
• Maximum temperature of +50°C
• Moving iron element
• RS PRO series
