KSJ100D80-L(068), i-Autoc KSJ Series Solid State Relay, 80 A Load, Panel Mount, 100 V dc Load, 32 V dc Control, Реле

KSJ100 (068) Series Solid State Relay

The KSJ100(068) series is a DC output, panel mounted solid state relay. With a control voltage of 4 to 32 V dc, load voltage of 0-100V dc, output current of 20A,40A or 80A. Opto-isolation between input and output and a dielectric strength of ≥2500VACrms. Applications suitable for DC heating, DC power, DC valve, DC motor, solar energy and many more.

IP20 touch safe cover
Ratings 20 A, 40 A, 80 A @ 100 V dc
4 to 32 V dc control input
Dielectric Strength ≥2500VACrms
Minimum turn on voltage 4 V dc
Minimum turn off voltage 1 V dc
Operating temperature -30℃ to +80℃
Weight 90g
Opto-isolation
Panel mounted
RoHS compliant

KSJ100(068) Series DC Output Solid State Relay

Approvals

RoHS

Zero Voltage Relays

Note

Temperature can affect current rating; please consult the data sheet for potential derating.
