PAXI0020, Red Lion PAXI Counter, Dual Counter, Rate Meter, Slave Display Counter, 5 Digit, 85 → 250 V ac, Счетчик

PAX I - counter, tachometer, with RS232 option

6-digit, 2 independent counters, 1 total/difference/remote indicator, 1 tachometer
Max. 40 kHz, adjustable to all common sensors
Plug-in options: 2 or 4 maximum values, analogue output: 0 / 4 → 20 mA, 0 → 10 V, serial interface: RS 232
Position display with analogue output
Easy to programme on the unit or via PC
Min./max. value storage, scalable pulse output
Protection class IP65
Dimensions: 48 x 96 x 104 mm

Red Lion Digital Counter

The Red Lion PAXI series digital counter is a 5-digit LED green display which offers a counter, dual counter, rate meter and slave display functions. Its voltage rating ranges between 85VAC and 250VAC. Communication and bus capabilities include RS232, RS485, Modbus, DeviceNet and Profibus-DP. Readout values and setpoint alarm values can be controlled through the bus.

Features and Benefits

Red, sunlight readable and variable intensity display
3 programmable keys
Four setpoint alarm outputs (with option cards)
Bus capabilities such as DeviceNet, ModBus and ProfiBus-D
Retransmitted analogue output
10-point scaling for non-linear processes
Panel cut-out size is 1/8 DIN
Plug-in screw terminal
Operating temperature ranges between 0°C and 50°C

Applications

Industrial counting applications
Control and monitoring systems
Manufacturing assembly lines

Certifications

cULus
CSA Certified
NEMA 4X
IP65 rated
