1462042-8, TE Connectivity, 5V dc Coil Non-Latching Relay SPDT, 4A Switching Current PCB Mount, Single Pole, Реле

TE Connectivity IM-C Signal Relays

IM-C signal relays with a compact slimline design and a high mechanical shock resistance. With a 10x6mm footprint and a low profile of 5.65mm these IM-C relays are ideal for use in applications that require a high PCB density design. These IM-C signal relays have a switching current of 4A and are SMT mounting with gull-wing style terminals. The contacts of these IM-C SMT relays are bifurcated for a stable mechanical operation, improved electrical contact and heat dissipation. Typical applications for these IM-C relays include telecommunications, modems, access and transmission equipment, office equipment, optical network terminals, test and measurement equipment, consumer electronicsa, industrial control and medical equipment.

Compact, slimline design, occupies just 60mm² board-space
60W/62.5VA switching power
220VDC/250VAC switching voltage
Bifurcated contacts for improved electrical performance
High resistance to mechincal shock
