Kestrel 0852HVG Impeller 40m/s Max Air Velocity Air Flow, Altitude, Density, Density Altitude, Dew Point, Evaporation, Анемометр

Kestrel 5200 Professional Weather Meter

The choice of Kestrel 5200 models is between the basic 0852HVG ( 914-0006 ) and the Bluetooth LiNK 0852LHVG ( 914-0009 ). Both offer distinctive monitoring functions for evaporation rate (lb/ft²/hr, kg/m²/hr), air flow (CFM, m³/hr, m³/m, m³/s, L/s), Delta T, Relative Air Density (RAD) & Air Density (lb/ft³, kg/m³). These functions make the 5200 an instrument of choice in agriculture, building construction and building services commissioning, operation and maintenance. Farmers use it for applications ranging from assessment of barn ventilation to chemical spraying (environmental conditions, correct spray nozzle, evaporation rate). Building engineers may enter the temperature of a concrete mix (from probe or IR thermometer) then measure conditions at the pour site to inform decisions about additives to the mix or curing adjustments, preventing costly shrinkage cracking of the slab. Building services engineers may input duct shape/dimensions and then simply traverse the 5200 across the duct for volume air flow data to assist in the commissioning and performance balancing of HVAC systems.

Evaporation Rate
Delta T
Air density
Relative air density (RAD)
Heading (true & magnetic)
Wind direction
Crosswind
Headwind/tailwind
Altitude
Pressure trend
Barometric pressure
Wet bulb temperature
Relative humidity in %
Heat stress index
Dewpoint
Density altitude
Wind chill
Air, water and snow temperature °F or °C
Current, average and maximum air velocity
Waterproof (sealed to IP67) and floats
Time and date
Easy- to-read backlit display
Data Logger (automatic and manual)
Data storage can be customised - 2900 data points
Minimum, Maximum and Average values
Multi-function 3-line display
Exterior temperature, humidity and pressure sensors for fast and accurate readings
Screens can be customised to display user-selected measurements
Graph and recall trends
User-replaceable impeller
Flip-top impeller cover protects the impeller while allows use of other instrument functions
Data charting
Multiple languages (English, French, Spanish, German, Italian)
Rugged (drop tested to MIL-STD-810G standards)
US Patent Nos. 5,783,753 and 5,939,645 and 6,257,074
Made in USA

Note

The Kestrel 5200 upgrades and combines functions previously available with the Kestrel 4250 and Kestrel 4300. The Kestrel 5200 Bluetooth LiNK version 0852LHVG includes custom communication software to configure data transmission frequency, download logged data, graph data and transfer data to other applications.

Supplied with

Neck lanyard, AA lithium battery, protective drawstring pouch, certificate of conformity, instruction manual

Datasheet

Contains SVHC - 1,2-dimethoxyethane; ethylene glycol dimethyl ether (EGDME) - CAS No. 110-71-4

Contains SVHC - 1,2-dimethoxyethane; ethylene glycol dimethyl ether (EGDME) - CAS No. 110-71-4
