RS PRO Enclosed Linear Power Supply, 230V ac Input, 24V ac Output, 1A Output, 24VA, Источник питания

RS PRO Embedded Linear Power Supply Enclosed, 230 V AC Input, 24 V AC Output, 1 A, 24 VA

This embedded linear power supply from RS PRO is a durable and weatherproof option for a wide range of applications. It's designed for wall mounting and housed in a tough enclosure that's IP66 rated for protection against both dust and high-powered jets of water.

This power supply can be easily replaced due to its intuitive wiring system – although you aren't likely to be doing that often, as it has a mean time between failure of 50,000 hours. The unit is equipped with a range of standard safety features that protect it against short-circuiting, overheating and over-voltage.

As part of the RS PRO series, this power supply has been stringently tested to ensure a reliable product. It's rated CEC level 'V' for efficiency and meets CE and EMC (electromagnetic compatibility) safety standards.

Linear power supplies of this type are suitable for outdoor applications such as communications and signalling equipment.

Features and Benefits

• Embedded linear power supply
• Enclosed mounting type
• Power rating of 24 VA
• Input voltage of 230 V AC
• Output current of 1 A
• Output voltage of 24 V AC
• Depth of 89.9 mm
• Width of 122.2 mm
• Length of 187.2 mm
• Maximum operating temperature of +40°C
• Minimum operating temperature of 0°C
• Mean time between failures of 50,000 hours
• Weight of less than 1.5 kg
• IP66-rated as dust-tight, protected against high-powered jets of water
• Conforms to CE and EMC safety standards
• CEC rating of level V for efficiency
• Conforms to Electrostatic Control Standards ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007
• RoHS (Restriction of Hazardous Substances) compliant

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
